Photovoltaic Power Cable and Wire from China manufacturer

Payment Terms:	T/T,L/C
Place of Origin:	Zhejiang, China (Mainland)

Product Detail

Model No.: QS-04

Packing: As per requirement

Application: Power Station

Insulation Material: Others

Brand Name: Qinshan

Means of Transport: Ocean,Land

Delivery Date: 20 days

Type: Low Voltage

Conductor Material: Copper

Photovoltaic Power Cable

Conductor: Tinned copper strands, according to VDE 0295/IEC 60228 class 5

Insulation: Polyolefin copolymer electron-beam corss linked

Jacket: Polyolefin copolymer electron-beam cross linked

Jacket colour: All colours

Rated Voltage: U0/u=600/1000V AC; 1000/1800V DC

Test Voltage: 6500V, 50Hz, 5 minutes

Working Temperature: -40℃ to +120℃

Short Circuit Temperature: 280℃

Bending Radius: Fixed installation >4 times of diameter ; Occasionally moved >5 times of diameter

Materaial properties / Standard: Fire performance: IEC 60332-1

Smoke emission: IEC 61034 ; EN50268-2

Low fire load: DIN 51900

Approvals: VDE-AR-E 2283-4 PV1-F

Application standards: UNE 21123; UNE 20.460-5-52, UTEC 32-502
